What size range hood insert do I need for a 48-inch range?

For a 48-inch range, start with a 48-inch insert, then confirm the exact width, height, and depth for the specific model you're considering, since depth alone ranges from 19 to 21 inches across Victory's Q5, Star, and Typhoon. Each product page includes its own dimensions diagram for exactly this purpose. Confirm the fit before installing, since installed or used items aren't eligible for return under Victory's return policy.

How much CFM do I need for a 48-inch range hood insert?

CFM needs depend on your range's burner output and cooking style, not on hood width alone. Victory's 48" Inserts offer three power tiers. The Q5 runs 600 CFM on a 6-inch duct or 750 CFM on an 8-inch duct. The Star delivers a steady 900 CFM and is built for high-BTU cooking and gas stoves. The Typhoon reaches 1000 CFM on an 8-inch duct or 1200 CFM on a 10-inch duct for heavy-duty ventilation. In many U.S. homes, the Typhoon's top CFM requires a make-up air system to replace the exhausted air, so check your local code before installing.

What size duct do I need to install a 48-inch range hood insert?

Duct size depends on which model you choose, since it directly affects the CFM you get. Victory's 48" Inserts use different duct configurations: the Q5 includes both 6-inch and 8-inch exhaust connectors, the Star uses a fixed 8-inch duct, and the Typhoon includes both 8-inch and 10-inch duct transitions, plus top and rear-exhaust transitions in the box. Since duct size varies this much across models, it's worth checking what you're working with before you choose: if you're replacing an existing insert, matching the new model to your current duct opening can simplify the install, and stepping up to a larger duct size may mean modifying existing ductwork.

How loud are Victory's 48-inch range hood inserts?

Sones measure perceived loudness, how loud a sound seems to the human ear, and the rating climbs as fan speed increases rather than staying fixed. Victory's 48" Inserts range from 1 to 6.6 sones across the lineup. The Q5 runs from 1 to 4.5 sones, the Star from 1 to 6 sones, and the Typhoon from 1.2 to 6.6 sones. Because the sone rating varies with fan speed, the published maximum reflects the noise level at the higher end of the blower's operation; actual sound in your kitchen can also vary with ducting and installation.

What warranty and certifications come with Victory's 48-inch range hood inserts?

Victory's 48" Inserts, the Q5, Star, and Typhoon, all currently list a Lifetime Motor Warranty plus 5-year parts coverage on their individual product pages. Per Victory's warranty policy, this coverage applies to the original owner only, is non-transferable, and requires registering within 90 days of delivery along with proof of purchase. All three models are also cETLus certified for the United States and Canada, conform to UL 507, and are certified to CSA C22.2 No. 113. One condition worth knowing before you buy: the warranty is void if the insert is used commercially. Full coverage details and exclusions are listed on Victory's warranty policy page.

48" Inserts

Victory's 48" Inserts are range hood inserts built to fit inside a custom 48-inch cabinet or hood shell. Three models span 750 to 1200 CFM (Cubic Feet per Minute, a measure of airflow), so you can match the power level to your own cooking style instead of guessing. Depth ranges from 19 to 21 inches across the lineup, with duct sizes from 6 to 10 inches depending on the model. Every insert carries a lifetime motor warranty, 5-year parts coverage, and cETLus, UL 507, and CSA certification.

Sort by

Compare

48 inch range hood insert with 900 CFM blower and 21 inch deep stainless steel design

48 inch 900 CFM Range Hood Insert - VICTORY Star

$2,499.00 - $2,499.00

$2,499.00

$2,499.00 USD

$2,499.00 - $2,499.00

$2,499.00 USD

If you have ever seared a steak on your front burners only to watch smoke bypass your hood and settle into your fabrics, you have experienced the "...

View full details

Compare

48 Inch 1200 CFM Range Hood Insert - VICTORY Typhoon

$2,999.00 - $2,999.00

$2,999.00

$2,999.00 USD

$2,999.00 - $2,999.00

$2,999.00 USD

Protect your custom kitchen investment from the invisible damage of high-heat cooking. Most standard inserts are too shallow, allowing up to 30% of...

View full details

Compare

48 Inch 750 CFM Range Hood Insert with stainless steel filters and dimmable LED lights by VICTORY Q5

48 Inch 750 CFM Range Hood Insert - VICTORY Q5

$2,399.00 - $2,399.00

$2,399.00

$2,399.00 USD

$2,399.00 - $2,399.00

$2,399.00 USD

The Q5 range hood insert is designed and assembled in Canada, this range hood insert is made with high quality mechanical switches, an all metal bl...

View full details

48" Inserts

Filters

48 inch 900 CFM Range Hood Insert - VICTORY Star

48 Inch 1200 CFM Range Hood Insert - VICTORY Typhoon

48 Inch 750 CFM Range Hood Insert - VICTORY Q5
